Characteristic/Characteristic
◆ New shock-proof and electronic synchronization, suitable for high speed precision parts processing;
◆ Easy to disassemble material pipe, fast and easy to maintain;
◆ Replace the bar material without adjusting the clamping tool;
◆ PLC plus servo, touch screen control, data operation, easy to use;
◆ Electrical and mechanical faults can be diagnosed by themselves, easy and fast maintenance.
| 项目 | LSCN-312 | LSCN-316 | LSCN-320 | LSCN-326 | LSCN-328 | |
| Processing capacity | 棒料加工MAXIMUM直径 | Φ12mm | Φ16mm | Φ20mm | Φ25mm | Φ28mm |
| Bar machining maximum diameter | ||||||
| 棒料加工MINIMUM直径 | Φ3mm | Φ3mm | Φ3mm | Φ3mm | Φ3mm | |
| Bar machining minimum diameter | ||||||
| 棒料加工长度 | 2500mm-3000mm | |||||
| Length of the bar machining | ||||||
| 料仓活动范围 | Φ13mm | Φ17mm | Φ21mm | Φ26mm | Φ29mm | |
| The channel activities range | ||||||
| Other | 棒材容量 /Material capacity | Φ12×31pcs | Φ16×23pcs | Φ20×19pcs | Φ25×10pcs | Φ28×13pcs |
| 总电气容量/Required eiectric power | 0.96kw | |||||
| 机床重量 / Weight of machine | 约 460kg | |||||
