Characteristic/Characteristic
◆ Easy to disassemble channel, bar change is fast and convenient;
◆ Tooth row feeding, no need to adjust the press and clamping tool when replacing the product;
◆ Synchronous wheel combined with ball slider, feed power control more delicate and accurate
| Item | LSCN-112 | ||
| Processing capacity | MAXIMUM diameter of bar processing | Φ12mm | |
| MINIMUM diameter for bar machining | Φ1mm | ||
| Bar processing length | 2500mm-3000mm | ||
| Adaptable material diameter (mm) | Φ6mm channel | Φ13mm channel | |
| Φ1.5-Φ4 | Φ3-Φ10 | ||
| Other | 棒材容量 /Material capacity | Φ10×21pcs | |
| 总电气容量/Required eiectric power | 0.96kw | ||
| 机床重量 / Weight of machine | About 460kg | ||
